Description of the Inline Controller
7805_en_02 PHOENIX CONTACT 2-23
Elements of the T_COM_PARAMETER data structure
The following describes the elements of the data structure and which settings are
supported by the ILC 130 ETH, ILC 150 ETH, ILC 155 ETH, and ILC 170 ETH 2TX Inline
Controllers.
X : Setting supported
– : Setting not supported
Protocol (protocol) ILC 13..., ILC 15..., ILC 17...
Code Description
00
hex
Transparent,
data is transmitted without modification
X
01
hex
––
02
hex
––
Baud rate (baudrate) ILC 13..., ILC 15..., ILC 17...
Code Description
00
hex
110 –
01
hex
300 –
02
hex
600 –
03
hex
1200 X
04
hex
Not used –
05
hex
2400 X
06
hex
4800 X
07
hex
9600 X
08
hex
19200 X
09
hex
38400 X
A
hex
57600 X
B
hex
115200 X
Data width (databits) ILC 13..., ILC 15..., ILC 17...
Code Description
00
hex
7 data bits, no parity –
01
hex
7 data bits, even parity –
02
hex
7 data bits, odd parity –
03
hex
8 data bits, no parity –
04
hex
8 data bits, even parity X
05
hex
8 data bits, odd parity –
