UM EN ILC 1XX
2-22
PHOENIX CONTACT 7805_en_02
T_COM_PARAMETER data structure
The T_COM_PARAMETER data structure is used to specify the settings for initialization.
• Program the following structure in your application program.
TYPE
T_COM_PARAMETER : STRUCT
protocol : INT;
baudrate : INT;
databits : INT;
stopbits : INT;
flowcontrol : INT;
error_pattern : INT;
first_delimiter : INT;
second_delimiter : INT;
XON_pattern : INT;
XOFF_pattern : INT;
END_STRUCT
END_TYPE
