Technical data and ordering data
7805_en_02 PHOENIX CONTACT 5-7
Conformance with EMC directive 89/336/EEC
Noise immunity test according to EN 61000-6-2
Electrostatic discharge (ESD) EN 61000-4-2/
IEC 61000-4-2
Criterion B
6 kV contact discharge
8 kV air discharge
Electromagnetic fields EN 61000-4-3
IEC 61000-4-3
Criterion A
Field strength: 10 V/m
Fast transients (burst) EN 61000-4-4/
IEC 61000-4-4
Criterion B
Supply lines: 2 kV
Signal/data lines: 2 kV
Surge test EN 61000-4-5
IEC 61000-4-5
Criterion B
Signal/data lines: 1 kV
Supply lines: 0.5 kV
Conducted interference EN 61000-4-6
IEC 61000-4-6
Criterion A
Test voltage 10 V
Noise emission test according to EN 61000-6-4
Noise emission of housing EN 55011 Class A
Approvals
For the latest approvals, please visit www.phoenixcontact.com.
