RAD-...-IFS
160 / 198
PHOENIX CONTACT 105542_en_05
Mounting and configuration Typ e Order No. Pcs./Pkt.
DIN rail connector for DIN rail power supply, gold-plated
contacts, for DIN rail mounting, 5-pos.
ME 17,5 TBUS 1,5/ 5-ST-3,81
GN
2709561 10
Shield connection clamp for applying the shield on bus-
bars
SKS 8-SNS35 3062786 10
Vulcanizing sealing tape for external protection of adapt-
ers, cable connections, etc., roll length: 3 m
RAD-TAPE-SV-19-3 2903182 1
Memory stick for saving custom configuration data RAD-MEMORY 2902828 1
USB data cable for communication between the PC and
Radioline devices, energy supply for diagnostics and con-
figuration via the USB port of the PC, cable length: 2 m
RAD-CABLE-USB 2903447 1
Configuration sticks Typ e Order No. Pcs./Pkt.
Configuration stick for easy and secure network address-
ing, unique network ID
2.4 GHz, RF band 3
2.4 GHz, RF band 5
2.4 GHz, RF band 7
868 MHz, RF band 1
RAD-CONF-RF3
RAD-CONF-RF5
RAD-CONF-RF7
RAD-868-CONF-RF1
2902814
2902815
2902816
2702197
1
1
1
1
2.4 GHz antennas Typ e Order No. Pcs./Pkt.
Omnidirectional antenna, 2.4 GHz, gain: 2 dBi, polariza-
tion: linear, opening angle: h/v 360°/75°, degree of protec-
tion: IP65, connection: RSMA (male), including 1.5 m con-
necting cable and mounting bracket for wall mounting
RAD-ISM-2400-ANT-OMNI-2-
1-RSMA
2701362 1
Omnidirectional antenna with protection against vandal-
ism, 2.4 GHz, gain: 3 dBi, polarization: linear, opening an-
gle: h/v 360°/85°, degree of protection: IP55, connection:
RSMA (male), for control cabinet mounting (wall mounting
as an option), including 1.5 m connecting cable
RAD-ISM-2400-ANT-VAN-3-
0-RSMA
2701358 1
Omnidirectional antenna, 2.4 GHz, gain: 6 dBi, polariza-
tion: linear, opening angle: h/v 360°/30°, degree of protec-
tion: IP67, seawater-resistant, connection: N (female),
including mounting bracket and mast clips, ATEX and
IECEx approval
RAD-ISM-2400-ANT-OMNI-6-
0
2885919 1
