3.4.3 SERIAL COMMUNICATION CONNECTOR
USB connector with serial communication cable is provided as part of the PBR FMT150 package when purchased with the
PBR software to connect the PBR FMT150 with the computer. This connection has to be made for the communication of
the PBR FMT150 via the PBR software.
3.4.4 AUX1 CONNECTOR
AUX1 connector should be used for the CO
2
sensor, peristaltic pump, additional light or magnetic stirrer (please see page
22 for detail description of possible connection schemes).
3.4.5 AUX2 CONNECTOR
AUX2 connector is used primarily for the bubble interruption valve, but can be used also for CO
2
sensor, peristaltic pump,
additional light or PWM pump (please see Fig. 10 page 22 for detail description of possible connection schemes).
3.4.6 POWER SUPPLY CONNECTOR
The power supply unit is plugged into the FMT150 control unit via this connector.
3.4.7 SERVICE COMMUNICATION CONNECTOR
Service communication connector is designed only for servicing the FMT150 by the manufacturer.
Warning: NEVER CONNECT THE SERVICE CABLE TO THIS CONNECTOR (RED ARROW IN Fig. 8A)
WITHOUT PRIOR CONSULTATION WITH THE MANUFACTURER.
3.4.8 IDENTIFICATION LABEL WITH SERIAL NUMBER
Each Photobioreactor FMT150 produced has a serial number that corresponds with the serial number of the power supply
unit. These are always provided together and are not interchangeable. Prior to switching PBR FMT150 device ON make
sure that the serial number on the rear panel of the main body matches the serial number on the power supply (Fig. 8B).
Warning: Damage can occur when the power supply is incompatible with the PBR FMT150 device.
