Photon Systems Instruments FMT150 - Technical Specification Standards

© PSI (Photon Systems Instruments), spol. s r. o.
71
7.3 TECHNICAL SPECIFICATION STANDARDS
7.3.1 FMT150 400 ML
Measured chlorophyll Fluorescence Parameters:
Fo, Ft, Fm, Fm´, Fv/Fm. Other parameters can be calculated.
Vessel Capacity / Weight:
400 ml / 2.8 kg
Precision Controlled Temperature:
Standard (ambient temperature around 23 °C): 5 – 75 °C
Cooling and heating system:
200 W Peltier elements
Two Displays:
System control and actual temperature
Actinic and Saturating Light:
Two standard versions: one with blue and red LEDs (450 nm, 630 nm); the other with white and red LEDs. Light intensity
is adjustable from 0 ~ 1,500 µmol.m
-2
.s
-1
, with light upgrade 0 ~ 3,000 µmol.m
-2.
s
-1
. Other LED colors available as an
option.
OD – Optical Density Measurement:
Real time measurement of OD by two LEDs (735 nm for version FMT150.1, 720 nm for version FMT150.2, 680 nm for
both FMT 150.1 and FMT150.2)
Detector Wavelength Range:
PIN photodiode with 665 nm – 750 nm bandpass filters
Controlled Flow and Composition of the Bubbling Air:
Optional
Pumps:
Up to 8 peristaltic pumps (optional)
Probes (pH, O
2
, CO
2
):
Optional
BIOS:
Upgradeable firmware
Communication Port:
Serial-RS232 for FMT150.1
USB port for FMT150.2
Cultivation Vessel Material:
Glass, stainless steel, duralumin, silicone sealing
Size:
41.5 x 35 x 31 cm
Weight:
15.5 kg
Electrical:
90-240 V AC
