21
3.5.5 AUX2 CONNECTOR
AUX2 connector should be used primarily for the bubble interruption valve but can be also used for CO
2
sensor, peristaltic
pump, additional light (please see Fig. 10 on page 22 for detail description of possible connection schemes).
3.5.6 USB TR COMMUNICATION CONNECTOR
USB TR communication connector is designed only for servicing the FMT150 thermoregulator by the manufacturer.
Warning: NEVER USE THE USB TR CONNECTOR WITHOUT PRIOR CONSULTATION WITH THE
MANUFACTURER.
3.5.7 AUX3 AND AUX4 CONNECTORS
AUX3 and AUX4 connector are additional connectors that can be used for the CO
2
sensor, peristaltic pump, additional light.
3.5.8 POWER SUPPLY CONNECTOR
The power supply unit is plugged into the FMT150 control unit via this connector.
3.5.9 IDENTIFICATION LABEL WITH SERIAL NUMBER
Each Photobioreactor FMT150 has a serial number that corresponds with the serial number of the power supply unit.
These are always provided together and are not interchangeable. Prior to switching PBR FMT150 device ON make sure
that the serial number on the front panel of the main body matches the serial number on the power supply (Fig. 9C).
Warning: Damage can occur when the power supply is incompatible with the PBR FMT150 device.
