- Using a suitable screwdriver use leverage on the
upper and lower appendices to detach the sealant.
- Remove the final reduction cap complete with the
wheel axle, being careful not to drop the inter-
mediate gear.
- Remove the final reduction cap.
- Turn the shaft of the driven pulley until aligning a
slot with the axis of the intermediate bearing and
insert the specific tool.
Specific tooling
020918Y Clutch lock
