- Remove the nut and incorporated washer secur-
ing the pinion.
- The pinion is symmetrical: mark the outer surface
to avoid reversed reassembly.
- Remove the pinion and the specific tool.
CAUTION
CLEAN THE THREAD FROM ANY RESIDUAL THREAD-
LOCK.
Removing the hub bearings
REMOVAL
Removing the clutch shaft bearing
- Remove the screw and countersunk washer.
- Using the specific tools remove the bearing.
Specific tooling
020376Y Adaptor handle
020357Y 32 x 35-mm Adaptor
020363Y 20-mm guide
Beverly 400 E5 Engine
ENG - 113
