- Tighten the special screws to the specified tor-
que.
Locking torques (N*m)
Head cover screws 6 ÷ 7
Refitting the intake manifold
- Connect the rubber sleeve complete with throttle
body to the intake manifold.
- Place the clamps and tighten them to the speci-
fied torque.
Locking torques (N*m)
Throttle body clamp screws 1.3 ÷ 1.7
Splitting the crankcase halves
- Undo the twelve crankcase coupling screws.
- Separate the crankcase halves while keeping the
crankshaft in one of these two halves.
- Only after the halves have been separated, can
the crankshaft be checked.
CAUTION
WHILE OPENING THE CRANKCASES AND REMOVING
THE CRANKSHAFT, CHECK THAT THE THREADED
SHAFT ENDS DO NOT INTERFERE WITH THE MAIN BUSH-
INGS. FAILURE TO OBSERVE THIS PRECAUTION CAN
DAMAGE THE MAIN BUSHINGS.
Beverly 400 E5 Engine
ENG - 139
