and remove the supporting plate from
the swinging arm buffer.
•
Support the vehicle adequately with
the jack. Remove the engine - swinging
arm fixing pin operating on the nut and
the pin head.
•
The engine is now free.
Locking torques (N*m)
Engine swinging arm pin nut 33 ÷ 41 Lower
shock absorber clamp 33 ÷ 41 Rear brake callip-
er tightening screws 20 ÷ 25
Runner 125 - 200 Engine from vehicle
ENG VE - 123
