PIAGGIO Runner 125 - Expansion tank; Lower cover

Expansion tank
- Remove the front shield.
Remove the screw indicated in the photograph.
- Remove the cap momentarily to disconnect it
from the shield back plate by pulling it downwards.
- Disconnect the expansion tank from the support
anchored to the chassis.
- Prepare a container to collect the coolant.
- Remove the coolant in (top) and return (bottom)
pipes.
Assembly following the procedure in reverse or-
der.
See also
Legshield
Front central cover
- Remove the Gilera emblem placing a screwdriver
in the emblem right groove.
- Remove the screw indicated in the photograph
and remove the cover by pulling it upwards.
Lower cover
- Remove the footrests.
- Remove the 4 screws (2 per side) indicated in the
photograph of the front wheel compartment.
- Remove the two bottom screws (1 per side) of
the shield back plate, then lever the plastic parts
to reach the screws <A> indicated in the photo-
graph.
- Remove the lower cover.
Chassis Runner 125 - 200
CHAS - 280
