PIAGGIO Runner 125 - Front brake calliper

- Keep the brake pads in contact with the pistons
and insert the calliper in the brake disc.
- Fix the calliper to the crankcase with the two
screws with elastic washer at the prescribed tor-
que as shown in the photograph
- Fix the brake pipe joint to the calliper and tighten
at the prescribed torque
- Bleed the system and refit the rear wheel
Locking torques (N*m)
Brake calliper support clamping 20 ÷ 25 Nm
Brake pipe connection 20 to 25 N•m
Front brake calliper
Braking system Runner 125 - 200
BRAK SYS - 244
