PIAGGIO Runner 125 - Rear Brake; Front Brake; Rear Suspension; Crankcase and Crankshaft

Name Torque in Nm
M14 Ø 8.8 steel screw Iron, steel 145
REAR BRAKE
Name Torque in Nm
Rear brake disc screws(°) 5 ÷ 6.5
Rear brake calliper-pipe fitting 20 ÷ 25
Rigid / flexible pipe fitting 13 ÷ 18
Rear brake pump-pipe fitting 16 ÷ 20
Rear brake calliper fixing screws 20 ÷ 25
FRONT BRAKE
Name Torque in Nm
Oil bleed screw 8÷12
Disc tightening screw (°) 5 ÷ 6.5
Brake fluid pipe-calliper fitting 20 ÷ 25
Brake fluid pump-hose fitting 16 ÷ 20
Tightening screw for calliper support to the fork 20 ÷ 25
Screw tightening calliper to the support 42 ÷ 52
REAR SUSPENSION
Name Torque in Nm
Upper shock absorber clamp 33 ÷ 41
Lower shock absorber clamp 33 ÷ 41
Shock absorber-crankcase attachment bracket 20 ÷ 25
Rear wheel axle 104 ÷ 126
Muffler arm clamping screws 27 ÷ 30
FRONT SUSPENSION
Name
Torque in Nm
Fork leg screw 6 ÷ 7
Front wheel axle 45 ÷ 50
Fork plate screw 25 ÷ 34
CHASSIS
Name
Torque in Nm
Centre stand bolt 25 ÷ 30
Side stand bolt (°) 35 ÷ 40
Engine arm bolt - frame arm 33 ÷ 41
Swinging arm buffer nut 64 - 72
Frame-swinging arm bolt 64 - 72
Engine-swinging arm bolt 64 - 72
STEERING
Name
Torque in Nm
Upper steering ring nut 30 ÷ 33
Steering lower ring nut 10 ÷ 13 then loosen by 90°
Handlebar fixing screw 50 ÷ 55
Fixing screws for handlebar control assembly U-bolts 7 ÷ 10
ENGINE - COOLING
Product
Description Specifications
(°) Loctite 243 Medium-strength threadlock Apply LOCTITE 243 medium-strength
threadlock
CRANKCASE AND CRANKSHAFT
Name
Torque in Nm
Internal engine crankcase bulkhead (transmission-side half
shaft) screws
4 ÷ 6
Engine-crankcase coupling screws 11 ÷ 13
Starter motor screws 11 ÷ 13
Characteristics Runner 125 - 200
CHAR - 14
