Name Torque in Nm
Crankcase timing system cover screws (°) 3.5 ÷ 4.5
ENGINE - FLYWHEEL
Name Torque in Nm
Pick-Up clamping screws 3 ÷ 4
Stator assembly screws (°) 3 ÷ 4
Flywheel cover fixing screws 5 - 6
Flywheel nut 94 ÷ 102
Screw fixing freewheel to flywheel 13 ÷ 15
ENGINE - TRANSMISSION
Name Torque in Nm
Rear hub cover screws 24 ÷ 27
Driven pulley shaft nut 54 ÷ 60
Transmission cover screws 11 ÷ 13
Drive pulley nut 75 ÷ 83
Clutch unit nut on driven pulley 55 ÷ 60
Belt support roller screw 11 ÷ 13
ENGINE - CYLINDER HEAD
Name Torque in Nm
Manifold-silencer retaining bolt 15 ÷ 20
Nut fixing muffler to cylinder head 16 ÷ 18
Camshaft retention plate screw 4 ÷ 6
Timing chain tensioner central screw 5 - 6
Timing chain tensioner support screw 11 ÷ 13
Starter ground support screw 11 ÷ 15
Timing chain tensioner slider screw 10 ÷ 14
Inlet manifold screws 11 ÷ 13
Tappet set screw lock nut 6 ÷ 8
Starter ground screw 7 ÷ 8.5
Head fixing side screws 11 ÷ 12
Nuts fixing head to cylinder (*) 27 ÷ 29
Tappet cover screws 6 ÷ 7
Spark plug 12 ÷ 14
LUBRICATION
Name
Torque in Nm
Hub oil drainage plug 15 ÷ 17
Oil filter on crankcase fitting 27 ÷ 33
Engine oil drainage plug/mesh filter 24 ÷ 30
Oil filter 4 ÷ 6
Oil pump cover screws 0.7 ÷ 0.9
Screws fixing oil pump to crankcase 5 - 6
Oil pump control crown screw 10 ÷ 14
Oil pump cover plate screws 4 ÷ 6
Oil sump screws 10 ÷ 14
Minimum oil pressure sensor 12 ÷ 14
NOTE
Product
Description Specifications
(°) Loctite 243 Medium-strength threadlock Apply LOCTITE 243 medium-strength
threadlock
Overhaul data
Assembly clearances
Runner 125 - 200 Characteristics
CHAR - 15
