Characteristic
Standard thickness:
4 +0.2-0.2 mm
Max. deviation allowed:
0.1 mm
Front brake pads
Removal
- Preloosen the two fixing pins of the brake pads
- Remove the brake calliper
- Remove permanently the two pad fixing screws
- Check that there are no flaws or warping. If there
is, replace it.
- Check the thickness of the friction material is
more than 1.5 mm. If it is not, replace it
- The replacement must be made with greater re-
sidual thickness if the pad has not worn evenly. A
0.5 mm thickness difference in the residual friction
material is permitted
Braking system Runner 125 - 200
BRAK SYS - 250
