- Every 12,000 km, when the vehicle should be
serviced according to scheduled maintenance, it
is necessary to check the correct lubrication of the
driven pulley roller casing.
- In case the lubrication is not enough, the specific
grease should be applied manually on the roller
surface.
Recommended products
AGIP GREASE SM 2 Greasing the driven pulley
bushing
Soap-based lithium grease with NLGI 2 Molybde-
num Disulphide; ISO-L-XBCHB2, DIN KF2K-20
Inspecting the driven sliding half-pulley
- Remove the two internal grommets and the two
O-rings.
- Measure the movable half-pulley bushing inside
diameter.
- Check that the faying surface with the belt is not
abnormally worn.
- Check the riveted joints are functional.
- Check the evenness of the belt faying surface.
MOVABLE DRIVEN HALF-PULLEY DIMENSIONS
Specification
Desc./Quantity
Wear limit 0.3 mm
standard diameter Diameter 41.000 - 41.035 mm
maximum allowable diameter Ø 41.08 mm
Engine Runner 125 - 200
ENG - 132
