Drive-belt
During the wear checks foreseen in the scheduled
maintenance services at 6,000 km; 18,000 km;
etc., check that the rim bottom of the toothing does
not show signs of incisions or cracking (see figure):
The rim bottom of the tooth must not have incisions
or cracking; if it does, change the belt.
•
Check that the driving belt is not dam-
aged.
•
Check the width of the belt is adequate.
Characteristic
Driving belt - minimum width:
21.5 mm
Driving belt - standard width:
22.5 ± 0.2 mm
Engine Runner 125 - 200
ENG - 136
