Flywheel and starting
- Check the integrity of the internal plastic parts of the flywheel and the Pick-Up control plate.
Removing the flywheel magneto
- Lock the rotation of the Flywheel using a calliper
spanner.
- Remove the flanged nut M10X1.25
- Extract the flywheel with the extractor.
Specific tooling
020565Y Flywheel lock calliper spanner
020162Y Flywheel extractor
Locking torques (N*m)
Electric start-up flywheel nut: 40 ÷ 44 Nm
Inspecting the flywheel components
- Check the integrity of the internal plastic parts of the flywheel and the Pick-Up control plate.
Engine Runner 125 - 200
ENG - 148
