PIAGGIO Runner 125 - Page 179

Bush-
ing cat-
egory
Crank-
case
halves
category
Internal bush-
ing diameter
after fitting
Possible
fitting
A 1 29.025 ÷
29.040
Original
B 1 29.019 ÷
29.034
Original
and spare
2 29.028 ÷
29.043
C 2 29.022 ÷
29.037
Original
Match the shaft with two category 1 crank webs
with the category 1 crankcase (or cat. 2 with cat.
2) Furthermore a spare crankcase cannot be
matched with a crankshaft with mixed categories.
The spare crankshaft has half shafts of the same
category.
Crankcase
halves
Engine half
shaft
Bushing
Cat. 1 Cat. 1 B
Cat. 2 Cat. 2 B
Cat. 1 Cat. 2 A
Cat. 2 Cat. 1 C
N.B.
TO KEEP THIS POSITION OF THE BUSHINGS ON THE
CRANKCASE, FITTING IS FORCED ON STEEL RINGS IN-
SERTED IN THE CASTING OF BOTH CRANKCASE
HALVES.
N.B.
DO NOT TAKE THE MEASUREMENT ON THE TWO HALF-
SHELL COUPLING SURFACE SINCE THE ENDS ARE RE-
LIEVED TO ALLOW BENDING DURING THE DRIVING
OPERATION.
N.B.
CRANKCASES FOR REPLACEMENTS ARE SELECTED
WITH CRANKCASE HALVES OF THE SAME CATEGORY
AND ARE FITTED WITH CATEGORY B BUSHINGS (BLUE)
Characteristic
Standard driving depth
1.35 ÷ 1.6
Diameter of crankcase without bushing
32.953 ÷ 32.963
Runner 125 - 200 Engine
ENG - 179
