- Remove the clamp and cover with the airing filter
of the diaphragm chamber.
- Remove the 4 fixing screws shown in the figure
and the vacuum chamber cover.
WARNING
DURING THE REMOVAL OF THE CARBURETTOR COVER
TAKE SPECIAL CARE NOT TO RELEASE THE SPRING
ACCIDENTALLY.
- Remove the vacuum valve together with the di-
aphragm.
Engine Runner 125 - 200
ENG - 190
