- Remove the full silent bloc bracket
- Undo the silent bloc ring shown in the photograph
- Hold the full silent bloc bracket in the clamp
- Using the appropriate tool, remove the silent bloc
from the bracket from the side corresponding to
the inside of the vehicle. This is to guarantee the
tool is centred properly on the support
- Install a new silent bloc, making sure it aligns
properly with the reference tooth.
- Fit the silent blocs, making sure the chamfered
part of the silent bloc matches the chamfered part
of the bracket
Runner 125 - 200 Suspensions
SUSP - 233
