Refitting
Carry out the previous operations but in reverse order.
Locking torques (N*m)
Lower shock absorber clamp 33 ÷ 41 Upper shock absorber clamp 33 ÷ 41
Exhaust bracket
Removal
Remove the full muffler unit.
- Remove the two fixing screws of the bracket to
the engine crankcase
- Remove the split pin, the cover and the fixing nut
of the rear wheel axle and its spacer
- Remove the shock absorber lower clamp
Runner 125 - 200 Suspensions
SUSP - 237
