See also
Removal
Refitting
- Insert the brake pads
- Insert the fixing pin being careful to position the
clip with the ends towards the bleed screw as in
the photo.
- Insert the clip on the pin
- Fix the rear brake calliper to the bracket and
tighten the two screws to the specified torque.
Locking torques (N*m)
Rear brake calliper tightening screw 20 ÷ 25 Nm
Braking system Runner 125 - 200
BRAK SYS - 252
