The recharge system is provided with a three phase alternator with permanent flywheel.
The alternator is directly connected to the voltage regulator.
This, in its turn, is connected directly to the ground and the battery's positive terminal passing through
the 20A protective fuse.
The three-phase generator provides good recharge power and at low revs a good compromise is ach-
ieved between the generated power and idle speed stability.
Battery recharge circuit Runner 125 - 200
- 94
