Picotest M3500A - Page 45

45
Figure 4-9
 Remove the six screws as shown in Figure 4-10.
Figure 4-10
Warning! Two grounding cords that connect between the rear panel
and the left and right chassis are fastened by the screws pointed by blue
arrows in Figure 4-10. Make sure the connections are correct when you
re-install the rear panel.
Grounding cord
fastening screw
Grounding cord
fastening screw
