2-7Operating Manual: PSS SB 3006-3 Series
6: Programming device interface
RS 232 (minimum configuration: TxD, RxD, GND)/RS 485
7: User interface
RS 232/RS 485
8: Pushbutton for switching on and off the RS 485 termination on the
user interface
9: Supply voltage connection (24 VDC)
10: Inputs and test pulse outputs
11: LED for status of SafetyBUS p 0
12: SafetyBUS p interface (SafetyBUS p 0)
13: LED for status of SafetyBUS p 1
14: SafetyBUS p interface (SafetyBUS p 1)
15: Rotary switch for setting the station address
16: Connection for temporary bus access (Network Access Port)
17: ControlNet interfaces (Channel A and Channel B)
18: LEDs for communication error with ControlNet (Channel A and B)
and to display operation (module and PSS)
19: Functional earth connection
INFORMATION
Please refer also to the manual: “ControlNet-Adapter for Compact 3rd
Generation PSS”.
