Supply Voltage
6-6 Operating Manual: PSS SB 3006-3 Series
Notes on wiring
• Minimum range for cable cross sections on field connection terminals in
mm
2
, in accordance with EN 61131-2, 07/00:
- Power supply: 1.5 (AWG16) ... 2.5 (AWG12)
- Functional earth: 1.5 (AWG16) ... 2.5 (AWG12)
• Use copper wiring.
• The torque setting on the terminals should be 0.5 … 0.6 Nm.
