Page #65 background imageLoading...
Page #65 background image
Operation and Maintenance
9-2 Operating Manual: PSS SB 3006-3 Series
Display elements
PSS functionality
LED
RUN ST
RUN FS
POWER
I0.0 ...
I0.5
Signal
Off
Lights green
Off
Lights green
Flashes green
Lights green
Off
Lights green
Key
Standard section of PSS in
“STOP”
Standard section of PSS in
“RUN”
Failsafe section of PSS in
“STOP”
Failsafe section of PSS in
“RUN”
Major error
Remedy: Read the error stack,
switch off the PSS, rectify the
error, switch on the PSS
The internally-generated 5 V supply
is within the permitted range.
Input has status “0”
Input has status “1”
SafetyBUS p functionality
LED “STATUS SB”
The LED lights as soon as the connection to SafetyBUS p is made.
Standard bus functionality
Various operating and fault statuses are displayed via the LEDs on the
various standard bus interfaces (see operating manual for the relevant
standard bus system).
