Function Description
4-4 Operating Manual: PSS SB 3006-3 Series
Slot
0
Sub-slot
0
Inputs/outputs
E0.0 - E0.5
Code
8004
H
Test pulse outputs
The two test pulse outputs T0 and T1 are suitable for testing the wiring of
input devices. All safety-related inputs must operate in accordance with
the failsafe principle (on switching off). Test pulses are allocated to inputs
via the configurator in the system software (PG). Each test pulse has a
maximum load capacity of 0.5 A.
INFORMATION
The test pulse outputs may not be used as digital outputs for safety
functions.
Configuration coding
The inputs are located on a sub-slot, which is allocated a code:
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Pilz PSS Series Specifications

General

Category	Safety Equipment
Manufacturer	Pilz
Safety Standards	EN ISO 13849-1, IEC 61508, IEC 62061
Series	PSS
Safety Integrity Level	SIL 3
Communication Interfaces	Ethernet, PROFIBUS, PROFINET
Operating Voltage	24 V DC
Operating Temperature	0°C to +55°C (typical), others depending on model
Storage Temperature	-20°C to +70°C (typical), others depending on model
Protection Class	IP20
Application	Industrial safety applications
