2-11Operating Manual: PSS SB 3006-3 Series
6: Programming device interface
RS 232 (minimum configuration: TxD, RxD, GND)/RS 485
7: User interface
RS 232/RS 485
8: Pushbutton for switching on and off the RS 485 termination on the
user interface
9: Supply voltage connection (24 VDC)
10: Inputs and test pulse outputs
11: Labelling strip for Ethernet address
12: ETH-2 interface with connection to ETHERNET via integrated switch
(2 free ports); LEDs on each port for
- Status of network connection (LINK)
- status of data traffic (TRAFFIC)
13: LED for status of SafetyBUS p 0
14: SafetyBUS p interface (SafetyBUS p 0)
15: LED for status of SafetyBUS p 1
16: SafetyBUS p interface (SafetyBUS p 1)
17: Functional earth connection
INFORMATION
Please refer also to the manual: “ETH-2 for Compact 3rd Generation
PSS”.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Pilz PSS Series Specifications

General

Category	Safety Equipment
Manufacturer	Pilz
Safety Standards	EN ISO 13849-1, IEC 61508, IEC 62061
Series	PSS
Safety Integrity Level	SIL 3
Communication Interfaces	Ethernet, PROFIBUS, PROFINET
Operating Voltage	24 V DC
Operating Temperature	0°C to +55°C (typical), others depending on model
Storage Temperature	-20°C to +70°C (typical), others depending on model
Protection Class	IP20
Application	Industrial safety applications
