Pilz PSS Series User Manual

Contents
2 Operating Manual: PSS SB 3006-3 Series
Digital inputs (DI2) 4-3
Test pulse outputs 4-4
Configuration coding 4-4
Installation 5-1
General requirements 5-1
Installing the safety system 5-2
Installing the safety system in a control cabinet 5-3
Supply Voltage 6-1
General requirements 6-1
Notes on wiring 6-6
Wiring the Inputs and Test Pulse Outputs 7-1
Configuration of the screw terminals and
connector description 7-1
Notes on wiring 7-2
Digital inputs (DI2) 7-4
Example: Single-channel, failsafe input device,
without test pulse 7-5
Example: Dual-channel input devices,
without test pulses 7-6
Example: Single-channel, failsafe input device,
with test pulse 7-7
Example: Dual-channel, failsafe input device, with test
pulses 7-8
Dedicated test pulse outputs 7-10
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Pilz PSS Series Specifications

General

Category	Safety Equipment
Manufacturer	Pilz
Safety Standards	EN ISO 13849-1, IEC 61508, IEC 62061
Series	PSS
Safety Integrity Level	SIL 3
Communication Interfaces	Ethernet, PROFIBUS, PROFINET
Operating Voltage	24 V DC
Operating Temperature	0°C to +55°C (typical), others depending on model
Storage Temperature	-20°C to +70°C (typical), others depending on model
Protection Class	IP20
Application	Industrial safety applications
