Operating Manual: PSS SB 3006-3 Series
7-9
24 V DC
L+
L-
0 V
T 0
T 1
I 0.0
I 0.1
I 0.2
I 0.3
I 0.4
I 0.5
X1
24 V DC
L+
L-
0 V
T 0
T 1
I 0.0
I 0.1
I 0.2
I 0.3
I 0.4
I 0.5
X1
Please ensure safety regulations and EMC guidelines are met!
Test pulse 0 Test pulse 1
Dual-channel input
device with identical
channels
Dual-channel input
device with identical
channels
Input for other input
devices
Test pulse 0 Test pulse 1
