PDP-433CMX
NSP 1 ADR CONNECT A Assy AWZ6678
NSP 2 ADR CONNECT B Assy AWZ6679
NSP 3 ADR CONNECT C Assy AWZ6680
NSP 4 ADR CONNECT D Assy AWZ6681
NSP 5 ADR RESONANCE Assy AWZ6751
NSP 6 BRIDGE A Assy AWZ6728
NSP 7 BRIDGE B Assy AWZ6729
NSP 8 BRIDGE C Assy AWZ6730
NSP 9 BRIDGE D Assy AWZ6731
10 SUB ADDRESS A Assy AWZ6692
11 SUB ADDRESS B Assy AWZ6693
NSP 12 SCAN (A) Assy AWZ6724
NSP 13 SCAN (B) Assy AWZ6725
14 Y DRIVE Assy AWZ6748
15 DIGITAL VIDEO Assy AWV1971
16 THERMAL SENSOR Assy AWZ6696
NSP 17 X CONNECTOR (A) Assy AWZ6726
NSP 18 X CONNECTOR (B) Assy AWZ6727
19 X DRIVE Assy AWV1985
20 MX AUDIO Assy AWZ6644
21 J209 Flexible Flat Cable ADD1206
22 J210 Flexible Flat Cable ADD1204
23 J211 Flexible Flat Cable ADD1199
24 J212 Flexible Flat Cable ADD1201
25 J201 Flexible Flat Cable ADD1183
•
UNDER LAYER SECTION (6) PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
26 J202 Flexible Flat Cable ADD1183
27 Flat Clamp AEC1879
28 J203 Flexible Flat Cable ADD1198
29 J205 Flexible Flat Cable ADD1202
30 J206 Flexible Flat Cable ADD1200
31 J207 Flexible Flat Cable ADD1208
32 J208 Flexible Flat Cable ADD1205
33 Power Sheet (43) AMR3284
34 Rivet BEC1066
35 J110 3P Housing Wire ADX2741
36 J108 8P Housing Wire ADX2740
37 J102 Wire PE ADX2738
38 J103 13P Housing Wire ADX2779
39 J116 4P Housing Wire ADX2783
40 J118 Wire L ADX2763
41 J119 13P Housing Wire ADX2768
42 J109 Wire X ADX2787
43 Binder AEC-093
44 J204 Flexible Flat Cable ADD1207
45 J104 Wire W ADX2786
46 J117 4P Housing Wire ADX2783
To Next Page
