Pioneer PDP-433CMX Service Manual

111
PDP-433CMX
5
678
5
6
7
8
C
D
F
A
B
E
Command Name Function
RS-232C
Factory
RS-232C
Integrator
Normal
Validity
Direct
Validity
UP/DOWN
Validity
A
ABL ABL ABL level adjustment O −−OO
B
BRT BRIGHT Brightness adjustment O O − OO
BHI B HIGH B HIGH adjustment O O − OO
BLW B LOW B LOW adjustment O O − OO
BSL B SIDE MASK LEVEL B SIDE MASK LEVEL adjustment O O − OO
BHA AD B HIGH AD B HIGH adjustment O −−OO
BLA AD B LOW AD B LOW adjustment O −−OO
C
CNT CONTRAST Contrast adjustment O O − OO
COL COLOR Color adjustment O O − OO
CDR CDR OFFSET CDR OFFSET adjustment O −−OO
CDB CDB OFFSET CDB OFFSET adjustment O −−OO
CTI CD TINT Chroma decode TINT adjustment O −−OO
CPH CLOCK PHASE PLL phase adjustment O O − OO
CFR CLOCK FREQUENCY PLL frequency adjustment O O − OO
D
DW0 DOWN 10 To decrease the adjustment value by 10 O O O −−
DWn DOWN n To decrease the adjustment value by n (n = 1, 2,•••8, 9) O O O −−
DWF DOWN FULL To decrease the adjustment value to the minimum O O O −−
G
GHI G HIGH G HIGH adjustment O O − OO
GLW G LOW G LOW adjustment O O − OO
GSL G SIDE MASK LEVEL G SIDE MASK LEVEL adjustment O O − OO
GHA AD G HIGH AD G HIGH adjustment O −−OO
GLA AD G LOW AD G LOW adjustment O −−OO
L
LRY R-Y LEVEL R-Y level adjustment O −−OO
LBY B-Y LEVEL B-Y level adjustment O −−OO
M
MCT MAT CONTRAST MAT CONTRAST adjustment O −−OO
MBR MAT BRIGHT MAT BRIGHT adjustment O −−OO
MCL MAT COLOR MAT COLOR adjustment O −−OO
MTI MAT TINT MAT TINT adjustment O −−OO
MCA AD MAIN CONTRAST AD MAIN CONTRAST adjustment O −−OO
P
PBH PANEL BLUE HIGH BLUE HIGH-LIGHT adjustment O −−OO
PBL PANEL BLUE LOW BLUE LOW-LIGHT adjustment O −−OO
PGH PANEL GREEN HIGH GREEN HIGH-LIGHT adjsutment O −−OO
PGL PANEL GREEN LOW GREEN LOW-LIGHT adjustment O −−OO
PRH PANEL RED HIGH RED HIGH-LIGHT adjustment O −−OO
PRL PANEL RED LOW RED LOW-LIGHT adjustment O −−OO
R
RHI R HIGH R HIGH adjustment O O − OO
RLW R LOW R LOW adjustment O O − OO
RSL R SIDE MASK LEVEL R SIDE MASK LEVEL adjustment O O − OO
RHA AD R HIGH AD R HIGH adjustment O −−OO
RLA AD R LOW AD R LOW adjustment O −−OO
S
SV1 SUB VOLUME INPUT1 To adjust the sub-volume of INPUT1 O O − OO
SV2 SUB VOLUME INPUT2 To adjust the sub-volume of INPUT2 O O − OO
SV3 SUB VOLUME INPUT3 To adjust the sub-volume of INPUT3 O O − OO
SV4 SUB VOLUME INPUT4 To adjust the sub-volume of INPUT4 O O − OO
SV5 SUB VOLUME INPUT5 To adjust the sub-volume of INPUT5 O O − OO
SHP H.SHARP H.SHARP/H.ENHANCE adjustment O O − OO
SHV V.SHARP V.SHARP/V.ENHANCE adjustment O O − OO
T
TNT TINT TINT adjustment O O − OO
U
UP0 UP10 To increase the adjustment value by 10 O O O −−
UPn UPn To increase the adjustment value by n (n = 1,2•••8,9) O O O −−
UPF UP FULL To increase the adjustment value to the maximum O O O −−
V
VOF VOFFSET ADJUST Vofs adjustment O −−OO
VOL VOLUME Audio volume adjustment O O O O O
VSU VSUS ADJUST Vsus adjustment O −−OO
VPS VERTICAL POSITION Vertical position adjustment O O − OO
VSI VERTICAL SIZE Vertical size adjustment O O − OO
X
XSB XSUS B X-SUS-B pulse adjustment O −−OO
XSG XSUS G X-SUS-G pulse adjustment O −−OO
Y
YSB YSUS B Y-SUS-B pulse adjustment O −−OO
YSG YSUS G Y-SUS-G pulse adjustment O −−OO
YDL Y-DELAY Y-DELAY adjustment O −−OO
YOL Y-OUT LEVEL Y-OUT LEVEL adjustment O −−OO
6.4 COMMANDS
6.4.1 RS-232C COMMANDS (for adjustment)
