Mark No. Description Part No. Mark No. Description Part No.
54
PDP-433CMX
LIST OF ASSEMBLIES
NSP SCAN FUKUGO ASSY AWV1969
SCAN (A) ASSY AWZ6724
SCAN (B) ASSY AWZ6725
X CONNECTOR (A) ASSY AWZ6726
X CONNECTOR (B) ASSY AWZ6727
BRIDGE A ASSY AWZ6728
BRIDGE B ASSY AWZ6729
BRIDGE C ASSY AWZ6730
BRIDGE D ASSY AWZ6731
NSP ADDRESS FUKUGO ASSY AWV1928
NSP ADR CONNECT A ASSY AWZ6678
NSP ADR CONNECT B ASSY AWZ6679
NSP ADR CONNECT C ASSY AWZ6680
NSP ADR CONNECT D ASSY AWZ6681
ADR RESONANCE ASSY AWZ6751
X DRIVE ASSY AWV1985
NSP Y DRIVE ASSY AWV1990
SLOT CONNECTOR ASSY AWZ6634
Y DRIVE ASSY AWZ6748
SUB ADDRESS A ASSY AWZ6692
SUB ADDRESS B ASSY AWZ6693
NSP DIGITAL VIDEO ASSY AWV1971
RGB VIDEO ASSY AWV1978
I/O ASSY AWZ6631
RGB ASSY AWZ6744
NSP MX FUKUGO ASSY AWV1976
CONTROL ASSY AWZ6633
SP OUT L ASSY AWZ6705
SP OUT R ASSY AWZ6706
SIDE KEY ASSY AWZ6637
THERMAL SENSOR ASSY AWZ6696
MX LED ASSY AWZ6642
IR ASSY AWZ6643
MX AUDIO ASSY AWZ6644
KEY CONNECTOR ASSY AWZ6695
Mark No. Description Part No.
Mark No. Description Part No.
5. PCB PARTS LIST
NOTES : ÷ Parts marked by “ NSP ” are generally unavailable because they are not in our Master Spare Parts List.
÷ The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
÷ When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex. 1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by
J = 5%, and K = 10%).
560 Ω = 56 × 10
1
= 561 ................................................... RD1/4PU 5 6 1 J
47k Ω = 47 × 10
3
= 473 .................................................. RD1/4PU 4 7 3 J
0.5 Ω = R50 ...................................................................... RN2H Â 5 0 K
1 Ω = 1R0 ......................................................................... RS1P 1 Â 0 K
Ex. 2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62k Ω = 562 × 10
1
= 5621 ........................................... RN1/4PC 5 6 2 1 F
SCAN (A) ASSY
SEMICONDUCTORS
IC6201-IC6206 SN755864APZP
D 6207 KU10N16
CAPACITORS
C6201,C6202,C6212,C6213 ACG1088
(0.1µF/250V)
C6222,C6223,C6232,C6233 ACG1088
(0.1µF/250V)
C6242,C6243,C6252,C6253 ACG1088
(0.1µF/250V)
C6203,C6205,C6220,C6231,C6235 CCSRCH151J50
C6251,C6259 CCSRCH151J50
C6262-C6266 CCSRCH151J50
C6206,C6210,C6215,C6219,C6227 CCSRCH181J50
C6229,C6236,C6240,C6244,C6246 CCSRCH181J50
C6255,C6266 CCSRCH181J50
C6208,C6209,C6217,C6218,C6226 CCSRCH331J5
C6230,C6238,C6239,C6245,C6250 CCSRCH331J5
C 6257,C 6258 CCSRCH331J5
C6204,C6207,C6214,C6216 CCSRCH390J50
C6224,C6225,C6234,C6237 CCSRCH390J50
C6248,C6249,C6254,C6256 CCSRCH390J50
C6211,C6221,C6228,C6241,C6247 CKSRYB105Z6R3
C6261 CKSRYB105Z6R3
RESISTORS
R6207,R6209,R6222,R6228,R6232 RAB4C221J
R6239 RAB4C221J
Other Resistors RS1/16S J
OTHERS
CN6201 15P CONNECTOR AKP1218
K6202,K6212,K6219,K6225,K6231 AKX9002
TEST PIN
K6239,K6244 TEST PIN AKX9002
