Description
Flow of basic automatic backup
Data in the EEPROM (IC1204/2 kbit) mounted on the DIGITAL VIDEO Assy are automatically copied to an area (Area A in the figure
below) of the EEPROM (IC5502/64 kbit) mounted on the RGB Assy as backup data in a case of assembly replacement.
Therefore, the adjustment data for the unit (data in the EEPROM of the DIGITAL VIDEO Assy) can be maintained even after replacement
of the DIGITAL VIDEO and/or RGB Assy.
Note: As for the COLOR and TINT items, even though they are adjustment data for the unit, as they are stored in Area C (see the figure
below) they are not automatically backed up.
Data in Areas A and B are judged according to keyword as to whether they have already adjusted or not, then copying is automatically
performed.
Contents of EEPROM on the DIGITAL VIDEO Assy
• Adjustment value of PANEL White Balance
PANEL-R HIGH : Adjustment item for the unit
PANEL-G HIGH : Adjustment item for the unit
PANEL-B HIGH : Adjustment item for the unit
PANEL-R LOW : Adjustment item for the unit
PANEL-G LOW : Adjustment item for the unit
PANEL-B LOW : Adjustment item for the unit
• Adjustment value of ABL
ABL LEVEL : Adjustment item for the unit
• Adjustment value of drive system
X-SUS-B : Adjustment item for the unit
X-SUS-G : Adjustment item for the unit
Y-SUS-B : Adjustment item for the unit
Y-SUS-G : Adjustment item for the unit
V-SUS : Adjustment item for the unit
V-OFFSET : Adjustment item for the unit
• Pulse meter
• Hour meter
• Various setting data of FULL MASK
Data are automatically backed up.
Data are automatically backed up.
Data are automatically backed up.
RGB Assy
EEPROM (IC5502)
DIGITAL VIDEO Assy
EEPROM (IC1204)
For copy (backup)
Data of the DIGITAL
VIDEO Assy
Data of the RGB Assy
Save area
Area A
Data of the DIGITAL
VIDEO Assy
Area B
Area C
1
2
1 Automatic copying is performed every time the Service Factory mode is entered (regardless of the
keyword.)
2 When the power is turned on, keyword checking is performed, then automatic copying is performed if
the keyword for the DIGITAL VIDEO Assy (Area B) is "not adjusted," and that for the RGB Assy is
"adjusted."
7.1.3 AUTOMATIC BACKUP OF DIGITAL VIDEO ASSY DATA
