Pioneer PDP-433CMX Service Manual

21
PDP-433CMX
2.9 MIDDLE LAYER SECTION (2)
3
11
7
29
9
4
5
1
9
12
6
6
12
1 IR Assy AWZ6643
2 MX LED Assy AWZ6642
3 J113 Wire O ADX2778
4 KEY CONNECTOR Assy AWZ6695
NSP 5 IR Holder ANG2494
6 Nyron Rivet AEC1671
7 J111 Wire Y ADX2788
NSP 8 Switch Holder ANG2493
9 Screw BMZ30P040FMC
10 • • • • •
11 V Cushion AED1205
12 Gascket R ANK1695
•
MIDDLE LAYER SECTION (2) PARTS LIST
Mark No. Description Part No.
