137
PDP-433CMX
5
678
5
6
7
8
C
D
F
A
B
E
1
Remove the rear case (M).(Screws × 20)
2
Remove the four screws.
3
Remove the SW Power Supply Module.
SW Power Supply Module
Diagnosis
4
Remove the clamper and insert it to another place, as
indicated in the photo below.
Clamper
Sub Frame L
Slit
SW Power Supply
Module
Sub Frame R
5
Insert the SW Power Supply Module into the slits
of sub frame L and R.
4
5
SW Power Supply
Module
SW Power Supply
Module
3
1
1
1 1 1 1 1
2
2
2
2
×2
×2
1
×2
1
×2
1
1
×2
11
1
1
7.1.4 DISASSEMBLY
