Pioneer PDP-433CMX Service Manual

9
PDP-433CMX
1 Packing Case See Contrast table (2)
2 Carton (43) AHD3100
3 Pad (43U) AHA2282
4 Pad (43L) AHA2283
5 Mirror Mat AHG1284
6 Power Cord Case AHC1037
7 Accessory Case Assy See Contrast table (2)
8 • • • • •
9 • • • • •
NSP 10 Polyethylene Bag See Contrast table (2)
11 Plasma Caution Sheet See Contrast table (2)
12 Plasma Caution Sheet See Contrast table (2)
13 Caution Sheet See Contrast table (2)
14 Caution Sheet ARM1194
15 Caution Sheet ARM1200
16 Caution Sheet ARM1201
17 Caution Sheet See Contrast table (2)
NSP 18 Warranty Card See Contrast table (2)
NSP 19 Warranty Card See Contrast table (2)
20 Remote Control Unit AXD1459
Mark No. Description Part No.
(1) PACKING PARTS LIST
Mark No. Description Part No.
21 Battery Cover AZN2462
NSP 22 Dry Cell Battery (R6P, AA) AEX1026
23 Power Cord See Contrast table (2)
24 Binder Assy AEC1758
(Speed Clamp × 2, Bead Band × 2)
25 Wiping Cloth AED1208
NSP 26 Polyethylene Bag AHG-064
27 Vinyl Bag AHG1310
28 Display Stand AMR3264
29 Remote Control Holder AMR3268
30 Hex Hole Bolt SMZ80H400FZB
31 Washer WB80FZB
32 Plasma Caution Sheet See Contrast table (2)
33 Operating Instructions See Contrast table (2)
(Japanese/English/French)
34 Operating Instructions See Contrast table (2)
(Spanish/Italian/Dutch)
35 Operating Instructions See Contrast table (2)
(English/French/German)
36 Ferrite Core See Contrast table (2)
37 Warranty Card Contens Label See Contrast table (2)
(2) CONTRAST TABLE
PDP-433CMX/LUCB and PDP-433MXE/YVLDK are constructed the same except for the following :
Mark No. Symbol and Description
Part No.
Remarks
PDP-433CMX PDP-433MXE
LUCB YVLDK
NSP
NSP
NSP
1
1
7
7
10
11
12
13
17
18
19
23
32
33
34
35
36
37
Packing Case (43CMX)
Packing Case (43MXE)
Accessory Cord Case(43CMX)
Accessory Cord Case(43MXE)
Polyethylene Bag Assy
Plasma Caution Sheet
Plasma Caution Sheet
Caution Sheet
Caution Sheet
Warranty Card
Warranty Card
Power Cord
Plasma Caution Sheet
Operating Instructions (Japanese/English/French)
Operating Instructions (Spanish/Italian/Dutch)
Operating Instructions (English/French/German)
Ferrite Core
Warranty Card Contens Label
AHD3130
Not used
AXX1058
Not used
AHG-195
ARM1145
ARM1147
ARM1176
ARM1203
ARY1093
ARY1102
ADG1208
Not used
ARD1052
Not used
Not used
Not used
AAX2911
Not used
AHD3134
Not used
AXX1059
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
ARM1149
Not used
ARC1510
ARE1365
ATX1031
Not used
