4.13 Speaker System: PDP-S07-LR (Can be used only with the PDP-433CMX/PDP-
433MXE)
4.13.1 Specifications
External dimensions ................. 74 (W) × 630 (H) × 101 (D) mm
(2-29/32 (W) × 24-13/16 (H) × 3-31/32 (D) in.)
1220 (W) × 630 (H) × 101 (D) mm (48-1/32 (W) × 24-13/16 (H) × 4-1/16 (D) in.)
(plasma display monitor when using PDP-433CMX or PDP-433MXE)
Weight ....................................... 1.6 kg (3.5 lbs.)
34.7 kg (76.5 lbs.) (plasma display monitor when using PDP-433CMX or PDP-433MXE)
Dimensions of packaging......... 694 (W) × 168 (H) × 318 (D) mm
(27-5/16 (W) × 6-5/8 (H) × 12-17/32 (D) in.)
Package weight......................... 4.6 kg (10.1 lbs.)
Cabinet....................................... Enclosed type, antimagnetic design
Used speakers (two-way method):
Woofer (for low tones) ....... Oval cone type
Tweeter (for high tones) .... 2.5 cm dome type
Nominal impedance ................. 8 Ω
Frequency Range ...................... 60 to 20,000 Hz
Sensitivity.................................. 82 dB/W (at 1 m distance)
Permissible input:
Max. input ............................ 12 W
Rated input .......................... 4 W
Crossover frequency................. 3 kHz
Accessory parts (for 2 speakers)
Speaker cable ...................................................... × 2
Flat countersunk head screw .............................. × 4
Hexagon socket head screw ............................... × 4
Mounting tool ...................................................... × 1
Washer M8 (ø25) ................................................ × 2
Speaker mounting fittings (bottom) ...................... x2
Speaker mounting fittings (top right) .....................x1
Speaker mounting fittings (top left) .......................x1
Mounting plate (for left side) ................................ x 1
Mounting plate (for right side) .............................. x 1
Warranty card ....................................................... x 1
Operating Instructions ......................................... x 1
Note
After this unit has been installed on the plasma display, you can’t use the display operation panel.
Cautions
The color may be irregular if there is a CRT type PC monitor close to it. To prevent this, keep the speaker separated from
a PC monitor.
Speaker System: PDP-S07-LR
[433CMX/433MXE]
