Wall-mounted tiltable plasma display hardware PDK-5011
4.6.2 External Dimensions
7 When using plasma display monitor PDP-503CMX or PDP-503MXE
(Units: mm)
6-φ10.5
6-23X10.5
98
33
35
150 150
35
35
714
44()
455
555
655
496
740
1218
545
465
232
212
410
143()
45
44 573
258()
54
43()
125
()
25°
C.L. (center of the display)
[503CMX/503MXE : 433CMX/433MXE]
7 When using plasma display monitor PDP-433CMX or PDP-433MXE
(Units: mm)
