53
Special Installation (Mounting to fittings)
35 mm or
less
Attach so that
the fan is on
the left side
viewed from
the rear.
Example 1
Example 2
Example 3
Example 4 Example 5
35 mm or
less
Example 6
Vertical installation
Standard installation
(Note that only Examples 1 and 2 apply in cases where top and bottom are reversed)
[433CMX/433MXE]
