83
7 Fix the bottom of the hardware with the special screws
removed at step 1 (one on the left and one on the
right).
Special screw (M6)
Wall-mounted tiltable plasma display hardware PDK-5011
Hook
6 Attach the hook on the PDP side hardware to the wall
side hardware.
Warning
Do not hold the speakers during the installation work.
[503CMX/503MXE : 433CMX/433MXE]
To Next Page
