[503CMX/503MXE : 433CMX/433MXE]Mobile Cart: PDK-5014
7 When using plasma display monitor PDP-433CMX or PDP-433MXE
(Units: mm)
150
(673)
660
600
30
59
220
60
440
(723)
630 (Stand shelf)
55
43
390
(Stand shelf)
300
100
337
496
666.6
32.3
961.5 (Panel)
312.5
35
555
98.5
100
1084.5
180
65
128.5
30
22
406
650
60
720
730 (Stand shelf installation spacing 40 mm)
770 (Stand shelf installed at the highest position)
773.5
1350 (Center of the display screen when it is installed at the upper position)
1170 (Center of the display screen when it is installed at the lower position)
1518.5
1314
1070
1665
132.3
75143.3 110
180
330 (Stand shelf installed at the
lowest position)
5°
(Tilt angle)
