Pioneer PDP-507CMX Service Manual

PDP-507CMX
124
1234
1234
C
D
F
A
B
E
Disassembly
Rear Case (507CMX) and Bottom Cover (CMX)
1
1
Remove the six screws. (TBZ40P080FTB)
2
Remove the 19 screws. (AMZ30P060FTB)
3
Remove the rear case (507CMX).
Front case Assy
Bottom cover (CMX)
Rear case (507CMX)
4
Remove the 17 screws. (AMZ30P060FTB)
×17
5
Remove the bottom cover (CMX).
Rear case (507CMX)
Bottom Cover (CMX)
Front Case Assy
2
1
Remove the four screws. (AMZ30P060FTB)
2
Pull the lower part of the front case Assy toward
you and out.
3
Remove the front case Assy, by pulling it upward.
1 111
2
3
3
1 1
2
2
2
2
2
2
2
2
2
2 2 2
2
2
2
4
5
2 2 2 2
1 1 1 1
