Pioneer PDP-507CMX Service Manual

PDP-507CMX
125
5678
56
7
8
C
D
F
A
B
E
Multi Base (CMX)
3
Audio Bracket (CMX)
4
3
Remove the six hex. head screws.
4
Remove the five screws.
5
1
Remove the rear case and the bottom cover.
2
Remove the two screws and the terminal panel MAIN.
Disconnect cables, connectors, as required.
6
Remove the multi base (CMX) with PC boards.
1
Remove the two screws.
3
• • • •
4
2
Remove the two screws and the treminal panel.
Then remove the COMM unit.
Remove the five screws.
6
Remove the three screws.
7
5
Remove the AUDIO Assy.
Disconnect cables, connectors, as required.
8
Remove the audio bracket (CMX) with PC boards.
AUDIO
Assy
COMMSLOT
Assy
COMMSLOT IF Assy
VSIF Assy
Multi base (CMX)
MAIN Assy
Audio bracket (CMX)
8
6
6
1 1
2 2
4
4
4
4 4
6
6
4
4
×6
3
