Pioneer PDP-507CMX Service Manual

PDP-507CMX
159
5678
56
7
8
C
D
F
A
B
E
8.4.7 PANEL REVISE (+)
< Lower-layer items of PANEL REVISE (+) >
No. Items Adjustment/Setting Value RS-232C Command
1 R-LEVEL <=> LV-0 to LV-7 RRL
2 G-LEVEL <=> LV-0 to LV-7 RGL
3 B-LEVEL <=> LV-0 to LV-7 RBL
<DOWN> : Shifting to ETC.(+)
<UP> : Shifting to PANEL-2 ADJ (+)
<SET> : Shifting to the next nested layer
Key operation
<DOWN> : Shifting to the next item
<UP> : Shifting to the previous item
<RIGHT> : Adding by one to the adjustment
value
<LEFT> : Subtracting by one from the
adjustment value
<SET> : Determining the setting value
and shifting to the upper layer
Key operation
L/1
[
BT60VS
]
ASPNEL E ERVI )(+
L/1
[
BT60VS
]
––>RL LEVE <=
ASEPNEL ERVI
V:L 0
A.PNEL FACT
B–SD 3 2060 –DIG HJ–B7
1
5
10
15
16
15 10 15 20 25 30 32
A.PNEL FACT
B–SD 3 2060 –DIG HJ–B7
1
5
10
15
16
15 10 15 20 25 30 32
• The degradation compensation level for white balance can be set.
