8.4.8 ETC. (+)
<Lower-layer items of ETC.>
<DOWN> : Shifting to RASTER MASK SETUP (+)
<UP> : Shifting to PANEL REVISE (+)
<SET> : Shifting to the next nested layer
Key operation
<DOWN> : Shifting to the next item
<UP> : Shifting to the previous item
<RIGHT> : Adding by one to the adjustment
value
<LEFT> : Subtracting by one from the
adjustment value
<SET> : Determining the setting value
and shifting to the upper layer
Key operation
Adjustment/Setting Value
L/1
[
BT60VS
]
TEC. )(+
L/1
[
BT60VS
]
ATABCKUPDA ><=
TEC.
O:N PRTO
A.PNEL FACT
B–SD 3 2060 –DIG HJ–B7
1
5
10
15
16
15 10 15 20 25 30 32
A.PNEL FACT
B–SD 3 2060 –DIG HJ–B7
1
5
10
15
16
15 10 15 20 25 30 32
No. Items RS-232C Command
1
2
3
4
5
6
7
8
BACKUP DATA <=> NO OPRT <=> TRANSFER or ERR BCP
DIGITAL EEPROM <=> NO OPRT <=> DELETE/REPAIR FAJ/UAJ
PD INFO. <=> NO OPRT <=> CLEAR CPD
SD INFO. <=> NO OPRT <=> CLEAR CSD
HR-MTR INFO. <=> NO OPRT <=> CLEAR CHM
PM/B1-B5 <=> NO OPRT <=> CLEAR CPM
P-COUNT INFO. <=> NO OPRT <=> CLEAR CPC
MAX TEMP. <=> NO OPRT <=> CLEAR CMT
• Settings concerning backup of adjustment values and clearance of the histories can be made.
