8.4.11 COMBI MASK SETUP (+)
L/1
[
BT60VS
]
AMSKOCMBI TSE UP )(+
L/1
[
BT60VS
]
M0CB SMA K 1
AMSK TSE UP
0:6 V
A.PNEL FACT
B–SD 3 2060 –DIG HJ–B7
1
5
10
15
16
15 10 15 20 25 30 32
A.PNEL FACT
B–SD 3 2060 –DIG HJ–B7
1
5
10
15
16
15 10 15 20 25 30 32
OCMBI
<DOWN> : Shifting to PANEL INFORMATION
(+)
<UP> : Shifting to RASTER MASK SETUP
(+)
<SET> : Shifting to the next nested layer
Key operation
<Lower-layer items of COMBI MASK SETUP (+) >
• The MASK indication sequence can be changed among 48V, 50V, 60V, 72V, 75V, 60P, and 70P, using the Right or
Left key. The selected sequence and the ABL/WB table are retained until the mask is turned off.
• 48V and 60P are represented by 50V and 60V, respectively. The ABL/WB table is changed to the PC table.
No. Items Adjustment/Setting Value RS-232C Command
1 MASK OFF MKC+S00
2 CMB MASK 01 <=>
<=> 48V <=> 50V <=> 60V <=> 60P
<=> 70P <=> 72V <=> 75V <=>
(Each sequence can be selected.)
MKC+S01
3• • • • • •
4 CMB MASK 10 <=> MKC+S10
<DOWN> : Shifting to the next MASK
<UP> : Shifting to the previous MASK
<RIGHT> : Changing MASK sequence (+)
<LEFT> : Changing MASK sequence (-)
<SET> : Determining the setting value
and shifting to the upper layer
Key operation
• Setting of COMBI MASK and setting of drive sequence during Combi Mask mode can be made.
